12V 80A 6 Terminal Winch Relay
  • 12V 80A 6 Terminal Winch Relay
  • 12V 80A 6 Terminal Winch Relay
  • 12V 80A 6 Terminal Winch Relay

12V 80A 6 Terminal Winch Relay

133616
AutoTruck42

12V - 80A - 6 TERMINALS

€42.65
VAT included
€35.54 VAT excluded
LIVRAISON 24/48H
Quantity
IN STOCK - IMMEDIATE DELIVERY

  Delivery policy

(edit with the Customer Reassurance module)





  Security policy

(edit with the Customer Reassurance module)

  Return policy

(edit with the Customer Reassurance module)

Description

SPECIFICATIONS:

Electrical Specifications
Voltage     12
Amp     80

Current Consumption     150 Amp.
Number of Sec.     5

Physical specifications
A     DE mm     41.85
B     Total length mm     89.65

Bracket
M     Coil bolt     M8
G     B+     M8
H     Height/B+     18.00
I     Kl. 15a/mm     M5
K     Kl. 50/mm     M5
N     Coil bolt l.     10.00
J     Width/kl. 15a     11.45
L     Width/kl. 50     11.45
No. terminals     6

More information
Remarks     Insulated return. Silver contacts.
Drawing     No36

Product Details
133616
New

Data sheet

Tension
12 Volts
Ampérage
80A
Nombre de bornes
6

Specific References

UPC
400000043944
EAN13
4000000043881
MPN
5705541126473
