Alternator 14V 35Amp, Denso 100211-1660, 100211-1661, 100211-1662, 100211-4530, 100211-4531, 100211-4700

Alternator 14V 35Amp, Denso 100211-1660, 100211-1661, 100211-1662, 100211-4530, 100211-4531, 100211-4700

• BRAND: BOSCH
• New Alternator
• warranty: 2 years
• Without Deposit
• Origin Quality

CHARACTERISTICS:
Electrical Information
Voltage 14
Amp. 35

Physical Information
At Dist. pulley 44.00
B Arm width 23.50
D Hole diameter 10.20
E Tensioner paste angle 60
G Leg hole diameter M8
H Pulley dia. 74.75
I Pulley grooves 1
J Radius 69.50
J Radius 2 66.00
K B + M6
K Position B+ in min. 5
L D+ Size Socket
N Rotation CW
O Socket not PL10
R Total length mm 143.00

Information Catalogs
Pulley Pulley
Regulator Type Ir
Vacuum Pump No
Product Info Bn
For Kubota

REPLACES THE FOLLOWING PART NUMBERS:
100211-1660 Denso
100211-1661 Denso
100211-1662 Denso
100211-4530 Denso
100211-4531 Denso
100211-4700 Denso
100211-4701 Denso
119620-77201 Yanmar
119620-77202 Yanmar
16771-64010 Kubota
16771-64012 Kubota
17580-64012 Kubota
27060-78001 Toyota
27060-78001-71 Toyota
27060-96001 Toyota
AM877740 John Deere
JA971IR HC-PARTS
RE72915 John Deere

COMPATIBLE WITH THE FOLLOWING VEHICLES:
Kubota, Industrial Engine
Various Agriculture Vehicles, Agricultural Machinery
Yanmar, Industrial Engine
