Alternator 14 Volts 50 A, Bosch 0986031641, Volvo 3292554, Citroen 570182, Renault 6000547927
  • Alternator 14 Volts 50 A, Bosch 0986031641, Volvo 3292554, Citroen 570182, Renault 6000547927
  • Alternator 14 Volts 50 A, Bosch 0986031641, Volvo 3292554, Citroen 570182, Renault 6000547927
  • Alternator 14 Volts 50 A, Bosch 0986031641, Volvo 3292554, Citroen 570182, Renault 6000547927

Alternator 14 Volts 50 A, Bosch 0986031641, Volvo 3292554, Citroen 570182, Renault 6000547927

111072

14 Volts - 50 Amp - RENAULT MASTER - RENAULT TRAFIC

€198.25
VAT included
€165.21 VAT excluded
LIVRAISON 24/48H
Quantity
IN STOCK - IMMEDIATE DELIVERY

  Delivery policy

(edit with the Customer Reassurance module)





  Security policy

(edit with the Customer Reassurance module)

  Return policy

(edit with the Customer Reassurance module)

Description

FEATURES:

Electrical Specifications
Voltage     14
Amp     50

Physical Specifications
D     Hole Diameter     10.50
G     Lug Hole Diameter     8.65
B     Arm Width     27.00
E     Tensioner Angle     60
C     Bracket Distance     66.00
H     Pulley Dia. 67.10
A     Dist. pulley     49.40
i     Pulley grooves     1
j     Radius     84.00
j     Radius 2     84.40
k     Position B +     M6
n     Rotation     Cr
o     Regulator connector     PL27
R     Total length mm     164.00

More information
Fan     If
Pulley     Pulley
Regulator type     Ir

REPLACES THE FOLLOWING PART NUMBERS:

Bosch: 0986031641, 0986032310, 0986032310090, 0986032311, 0986034801, 0986034801090, 0986037301, 9120144283, 9120144284.
Iskra: 11.201.469, 11201469, AAK3565, IA0469, IA0535.
Cargo: 111171.
Messmer: 210057, 210057R.
Valeo: 2181730, 2541156, 2541464, 432729, 432756, 433077, 433431, 433432, 433436, 433437, 433438, 433447, 433451, 433462, 436313, 436356, 439029, 439180, 451083, 510228, 516044A, 9AL2538K, A13N139, A13N14, A13N171, A13N228, A13N62, A13N63, A13N65, A13N82, A13N87, A13R198, A13R222, A13R228, A13R260, A13R269, A13R96, A14N53, A14N62, NA246, NA267, NA294, NA320, NA350, VA346.
Volvo: 3292554, 32925547, 9031046, 90310467.
Ducellier: 451076, 515016, 516017, 516024.
Citroen: 570182, 570189, 570212, 570231, 570250, 570531, 570542, 570567, 97501203.
Renault: 6000547927, 7700576795, 7700644580, 7700651809, 7700662371, 7700665612, 7700709420, 7700710964, 7700751401, 7700751442, 7700754113, 7700754831, 7700754835, 7700758336, 7700793594, 7701348311, 7701351762, 7701352316, 7701365469, 7701499208, 7701499218, 7701499258, 7701499286, 7701499440, 7701499451, 7701499456, 7701499459.
Dacia: 6000547927.
Delco: 932361, DRA2311, DRA3076, DRA4003, DRA4801, DRA7301.
Magneti marelli: 943356106010, 943356148, 943356185, 943356185010, 943356279, 943356561, 943356561010, 944390373010.
Peugeot: 97501203.
Motorola: 9AR2676, 9AR2676K, 9AR2752P, 9AR2778, 9AR2778K, 9AR2933P, 9AR2945, 9AR2948, 9AR2948K.
Krauf: ALV0165, ALV0224.
Motorherz: ALV0165WA.
HC-Parts: CA165IR, CA224IR, CA526IR.
Lucas: LRA00390, LRA00510, LRA00808, LRA00916, LRA01187, LRA02768, LRA285, LRA403,LRA808, LRA916.

COMPATIBLE WITH THE FOLLOWING ALTERNATORS:

RENAULT 20 (127_) 2.0 (1272) (1977-1980)
RENAULT 20 (127_) 2.0 (1277) (1980-1983)
RENAULT 20 (127_) 2.2 (1279) (1980-1983)
RENAULT 20 (127_) 2.1 Diesel (1276) (1980-1983)
RENAULT 20 (127_) 2.1 TD (1982-1983)
RENAULT MASTER I Van (T__) 28-35 2.1 D (1980-1998)
RENAULT MASTER I (T__) 28-35 2.1 D (1980-1998)
RENAULT TRAFIC Van (T1, T3, T4) 2.1 D (1980-1989)
RENAULT TRAFIC Van (T1, T3, T4) 2.1 D 4x4 (1986-1989)
RENAULT TRAFIC c (P6) 2.1 D (1980-1989)
RENAULT TRAFIC (T5, T6, T7) 2.1 D (1980-1989)
RENAULT TRAFIC (TXW) 2.1 D (1989-1994)
RENAULT TRAFIC (T1, T3, T4) 2.1 D (1980-1989)
RENAULT TRAFIC (T1, T3, T4) 2.1 D 4x4 (1986-1989)
VW CARAT (32B) 2.1 (1981-1983)
VW CARAT (32B) 2.1 (1981-1983)

Product Details
111072
New

Data sheet

Tension
14 Volts
Ampérage
50A

Specific References

UPC
400000044057
EAN13
4000000043997
