Altering 14V 95amp KHD 01181743, 01182038, 01182039, Deutz-Fahr 01182038

altering 14v 95amp KHD 01181743, 01182038, 01182039, Deutz-Fahr 01182038

• Brand: Bosch
• New altering
• Guaranteed: 2 years
• without instruction
• Original quality

Characteristics:
Electric information
Voltage 14
amp.     95
terminal W

Physical information
B Warm width 56.00
D Diameter of the hole 10.00
e Angle paste tensioner 10
g Diameter Trou de la Patte 10.00
J Radius 90.00
J Radius 2 90.00 + M8
k position B + in min.     55
L D+ Size M5
n Rotation CW
Q Type taken W M5
R Total length mm 193.00
Source Mahle Letrika

Information Catalogs
Pulley without
type Ir
for Deutz, Mercedes-Benz, Ssangyoung
Note to the chick.

replaces the following references:
01181743 KHD
01182038 DEUTZ-FAHR
01182038 KHD
01182039 KHD
01183183 KHD
01183427 KHD
05715374 Bomag
05716783 Bomag
05718621 Bomag
08821094 BOMAG
11.201.790 ISKRA
11.203.062 ISKRA
11.203.063 ISKRA
11.203.397 ISKRA
11.203.398 ISKRA
11.204.037 iskra
1171745 KHD
1181743 KHD
1182038 KHD
1182039 KHD
1183183 KHD
1183427 KHD
2050944
5716783 Bomag
aak5141 iskra
aak5335 iskra
aak5336 iskra
aak5566 iskra
aak5567 iskra} AAK5794 ISKRA

Compatible with the following vehicles:
MERCEDES-BENZ, light vehicle eu
MERCEDES-BENZ, trucks eu
ssangyong, light vehicle eu
Volvo
Volvo Penta, Marine
