Alternator 14V 35Amp Denso 121000-0600, Denso 121000-0980, Kubota 15253-64010, 15471-64010, 15621-64010

Alternator 14V 35Amp Denso 121000-0600, Denso 121000-0980, Kubota 15253-64010, 15471-64010, 15621-64010

• BRAND: BOSCH
• New Alternator
• Warranty: 2 years
• Without Deposit
• Quality Origin

CHARACTERISTICS:
Electrical Information
Voltage 14
Amp. 35

Physical Information
A Pulley Dist. 43.50
B Arm Width 13.00
C Pulley Dist. between bracket 67.40
D Hole diameter 8.50
E Tensioner paste angle 60
G Tab hole diameter 8.70
H Pulley dia. 75.00
I Pulley grooves 1
J Radius 78.00
J Radius 2 76.00
K B + M6
K Position B+ in min. 10
N Rotation CW
O Socket not PL15
R Total length mm 158.00

Information Catalogues
Pulley Pulley
Governor type Er
Product info Bn
For Kubota
Remarks Governor: HC-CARGO 130627.

REPLACES THE FOLLOWING PART NUMBERS:
121000-0600 Denso
121000-0980 Denso
15253-64010 Kubota
15471-64010 Kubota
15621-64010 Kubota
15621-64011 Kubota
15763-64010 Kubota
15763-64011 Kubota
15763-64012 Kubota
27020-23020 Toyota

FITS THE FOLLOWING VEHICLES:
Kubota, Industrial Engine
