Alternator 14V 65Amp Bosch 0124215002, 0124215005, Mako 063321615000, Fiat 46231699, 46407645

Alternator 14V 65Amp Bosch 0124215002, 0124215005, Mako 063321615000, Fiat 46231699, 46407645

• BRAND: BOSCH
• New Alternator
• Warranty: 2 years
• No Deposit
• Quality Origin

CHARACTERISTICS:
Electrical Information
Voltage 14
Amp. 65

Physical Information
A Pulley Dist. 41.00
B Arm Width 17.00
C Pulley Dist. between bracket 82.00
D Hole diameter 12.30
E Tensioner paste angle 4
G Tab hole diameter 11.00
H Pulley dia. 60.00
I Pulley grooves 6
J Radius 90.00
J Radius 2 90.00
K B + M8
K Position B+ in min. 15
L D+ Size M5
N Rotation CW
R Total length mm 199.00

Information Catalogues
Pulley Serpentine pulley
Regulator type Ir
Vacuum pump No
Product info Bn
For Fiat, Citroen

REPLACES THE FOLLOWING PART NUMBERS:
0124215002 Bosch
0124215005 Bosch
063321615000 Mako
46231699 Fiat
46407645 Fiat
46420964 Fiat
46420965 Fiat
46434932 Fiat
46434935 Fiat
46464276 Fiat
46540293 Fiat
5895029 Fiat
63320511 Magneti Marelli
63321204 Magneti Marelli
63321251 Magneti Marelli
63321275 Magneti Marelli
63321282 Magneti Marelli
63321362 Magneti Marelli
63321367 Magneti Marelli
63321615 Magneti Marelli
63321616 Magneti Marelli
63321660 Magneti Marelli
63321661 Magneti Marelli
63321820 Magneti Marelli
7721122 Fiat
7778020 Fiat
CA1084IR HC-PARTS

COMPATIBLE WITH THE FOLLOWING VEHICLES:
Citroen, Light vehicle EU
Fiat, Light vehicle EU
Peugeot, Light vehicle EU
